PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS

NEVOC SYSTEM

NEVOC SYSTEM

300 bar pressure rregulators with Nevoc international connection.


The trend to use increasingly higher filling pressures has led Oxyturbo to adopt the new NEVOC cylinder valve connection for industrial applications requiring a pressure of 300 bar.

NEVOC stands for New European Valve Outlet Connections. The NEVOC system was designed to facilitate the future harmonisation of gas cylinder connections throughout Europe. Recently, however, ISO 5145 has replaced the NEVOC system.

Use

High-quality engineering maintains stable regulation throughout the life of the cylinder, reducing gas consumption, promoting safety and increasing the efficiency of applications.We can supply models with outlet pressures from 10 to 100 bar, suitable for all types of inert gases including nitrogen, helium and argon particularly suitable for heavy cutting applications.

Certificates


MAXYMUM NEVOC - OUTLET 3/8 - OXYGEN

PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - NEVOC SYSTEM - MAXYMUM NEVOC - OUTLET 3/8 - OXYGEN

Lubrication of the inner sealing O-rings of the regulator is carried out using oxygen-compatible lubricant (specific grease). (Oxygen version only) The 60 bar version is Apragaz approved W30x2Rhi connection - ISO 5145.
Confronto tra codici, caratteristiche tecniche e documenti disponibili
Code Image Description Outlet P1 (bar) P2 (bar) Q1 (m³/h) Availability Weight (kg) No. of pcs Product sheet

290200.100NVC

Request information
NEVOC SYSTEM
 Maxymum OXYGEN Nevoc 100 bar G3/8+1/4 SAE 5/16 SAE 300 100 >200 R 1 1
--

290200.NVC

Request information
NEVOC SYSTEM
 Maxymum OXYGEN Nevoc 60 bar G3/8+1/4 SAE 5/16 SAE 300 60 <150 R 1 1
--

290200.40NVC

Request information
NEVOC SYSTEM
 Maxymum OXYGEN Nevoc 40 bar G3/8+1/4 SAE 5/16 SAE 300 40 <100 R 1 1
--

290200.20NVC

Request information
NEVOC SYSTEM
 Maxymum OXYGEN Nevoc 20 bar G3/8+1/4 SAE 5/16 SAE 300 20 <60 R 1 1
--

MAXYMUM NEVOC - OUTLET 3/8 - INERT GASES

PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - NEVOC SYSTEM - MAXYMUM NEVOC - OUTLET 3/8 - INERT GASES

The nitrogen version is particularly suitable for cleaning air conditioning systems or inflating tires. Available with four different pressure settings. The argon version is also ideal as a primary regulator for centralizations fed by cylinder packs up to 300 bar pressure.
W30x2Rhi connection - ISO 5145
Confronto tra codici, caratteristiche tecniche e documenti disponibili
Code Image Description Outlet P1 (bar) P2 (bar) Q1 (m³/h) Availability Weight (kg) No. of pcs Product sheet

294200.100NVC

Request information
NEVOC SYSTEM
 Maxymum INERT GASES Nevoc 100 bar G3/8+1/4 SAE 5/16 SAE 300 100 >200 R 1 1
--

294200.NVC

Request information
NEVOC SYSTEM
 Maxymum INERT GASES Nevoc 60 bar G3/8+1/4 SAE 5/16 SAE 300 60 <150 R 1 1
--

294200.40NVC

Request information
NEVOC SYSTEM
 Maxymum INERT GASES Nevoc 40 bar G3/8+1/4 SAE 5/16 SAE 300 40 <100 R 1 1
--

294200.20NVC

Request information
NEVOC SYSTEM
 Maxymum INERT GASES Nevoc 20 bar G3/8+1/4 SAE 5/16 SAE 300 20 <60 R 1 1
294200.20NVC_ENG.pdf

MAXY NEVOC - OUTLET 1/4 - OXYGEN

PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - NEVOC SYSTEM - MAXY NEVOC - OUTLET 1/4 - OXYGEN

A very solid structure for a vertically controlled regulator with lateral connection, designed and built to ensure accurate and safe use of gases. The ergonomic knob allows the user to adjust the flame during welding operations so that it always remains neutral and reducing.
They are particularly suitable for heavy cutting uses in the demolition sector and in the steel industry.
W30x2Rhi connection - ISO 5145
Confronto tra codici, caratteristiche tecniche e documenti disponibili
Code Image Description Outlet P1 (bar) P2 (bar) Q1 (m³/h) Availability Weight (kg) No. of pcs Product sheet

260200.NVC

Request information
NEVOC SYSTEM
 Maxy OXYGEN Nevoc 10 bar G1/4 PG 300 10 30 R 1 1
--

MAXY NEVOC - OUTLET 1/4 - INERT GASES

PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - NEVOC SYSTEM - MAXY NEVOC - OUTLET 1/4 - INERT GASES

Built for use with compressed gases up to 300 bar, they allow for high output values.
Recommended for tire fitting, fire extinguisher charging and arc welding.
W30x2Rhi connection - ISO 5145
Confronto tra codici, caratteristiche tecniche e documenti disponibili
Code Image Description Outlet P1 (bar) P2 (bar) Q1 (m³/h) Availability Weight (kg) No. of pcs Product sheet

266200.10NVC

Request information
NEVOC SYSTEM
 Maxy INERT GASES Nevoc 10 bar G1/4 PG 300 10 30 R 1 1
--

266200.NVC

Request information
NEVOC SYSTEM
 Maxy INERT GASES Nevoc G1/4 PG 300 4 32L/min R 1 1
--

266400.NVC

Request information
NEVOC SYSTEM
 Maxy with flowmeter INERT GAS Nevoc G1/4 PG 300 3,5 30L/min R 1 1
--

Technical questions and evidence

How can I compare the available variants?

Use the comparison table above: codes and technical properties come directly from the Oxyturbo product database.

Which supporting documents are available?

The technical sheets, manuals and certificates shown on this page are the documents currently associated with this product family.

How do I verify compatibility with my application?

Check gas, pressure, connection and flow data for the exact code, then send that code with the application requirements to Oxyturbo for confirmation.
