PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS
MAXYMUM
MAXYMUM
Professional pressure regulators for operating pressures up to 100 bar.
A new series of professional regulators obtained with brass bar production technology.
HIGH PRESSURE AND POWERFUL DISTRIBUTION
Allows for use of compressed gases up to 200 bar and enables high differential pressure output at 20/40/60/100 bar and flow rate superior than 200 m³/h.
Characteristics
- Approved by APRAGAZ for inlet pressure p1=300 bar
- The solid body made of brass bar guarantees resistance to hydraulic pressure of 450 bar without permanent deformation
- In addition to high-pressure and low-pressure machine marking, two threaded holes are present in the rear of the regulator body which allows regulator fastening for fixed wall applications.
- The high-pressure capsule is equipped with a new constant, limited high pressure tablet compression system. Combined with a piston pressure adjustment system, constructed entirely in brass, which ensures the best resistance even for the most heavy duty uses
- The pressure adjustment system, made with a plastic knob combined with an unremovable adjusting screw is particularly soft even at high pressures in the cylinder and makes it easier to reach the desired pressure
- The safety valve used to discharge overpressure in case of high pressure sys- tem breakage has been approved in accordance with EN ISO 2503.
- The injector connecting to the cylinder enables connection to cylinders with all types of valve protections present on the market.
- The easy to read 63 Ø pressure gauges are protected by suitably sized protective caps.
- MAXYMUM regulators are packaged in a lithographed box with double die-cut protection to prevent collisions caused during transport.
- Used in a host of applications thanks to its versatility.
Use
Designed for highly professional and industrial applications and equipped with an overpressure safety device.
Certificates
Product Sectors
MAXYMUM 100 BAR - NITROGEN
MAXYMUM 100 BAR - OXYGEN
MAXYMUM 100 BAR - ARGON
MAXYMUM 100 BAR - HYDROGEN
MAXYMUM 100 BAR - AIR
MAXYMUM 60 BAR - NITROGEN
MAXYMUM 60 BAR - OXYGEN
MAXYMUM 60 BAR - ARGON
MAXYMUM 60 BAR - CO2
MAXYMUM 60 BAR - HYDROGEN
MAXYMUM 60 BAR - AIR
MAXYMUM 40 BAR - NITROGEN
MAXYMUM 40 BAR - OXYGEN
MAXYMUM 40 BAR - ARGON
MAXYMUM 40 BAR - CO2
MAXYMUM 40 BAR - HYDROGEN
MAXYMUM 40 BAR - AIR
MAXYMUM 20 BAR - NITROGEN
MAXYMUM 20 BAR - OXYGEN
MAXYMUM 20 BAR - ARGON
MAXYMUM 20 BAR - CO2
MAXYMUM 20 BAR - HYDROGEN
MAXYMUM 20 BAR - AIR
MAXYMUM 100 BAR - NITROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 100 BAR - NITROGEN
Particularly suitable for cleaning air conditioning systems or inflating tires. Available with four different pressure settings.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE connections.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
294200.100 Request information | | MAXYMUM NITROGEN 100 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 100 | >200 | D | 1 | 1 | -- |
294209.100 Request information |  | MAXYMUM NITROGEN 100 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | D | 1 | 1 | -- |
294203.100 Request information |  | MAXYMUM NITROGEN 100 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | D | 1 | 1 | -- |
294202.100 Request information |  | MAXYMUM NITROGEN 100 BAR | NF-MIE | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | D | 1 | 1 | -- |
2942049.100 Request information |  | MAXYMUM NITROGEN 100 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | D | 1 | 1 | -- |
294204.100 Request information |  | MAXYMUM NITROGEN 100 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | D | 1 | 1 | -- |
294205.100 Request information |  | MAXYMUM NITROGEN 100 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | D | 1 | 1 | -- |
MAXYMUM 100 BAR - OXYGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 100 BAR - OXYGEN
The lubrication of the internal O-rings of the regulator is carried out using a lubricant (specific grease) compatible with oxygen, approved by BAM. (Bundesanstalt fur Materialforschung)
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
290200.100 Request information |  | MAXYMUM OXYGEN 100 BAR | UNI-SS | G1/4 | 200 | 100 | >200 | R | 1 | 1 | -- |
290201.100 Request information |  | MAXYMUM OXYGEN 100 BAR | DIN | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
290203.100 Request information |  | MAXYMUM OXYGEN 100 BAR | BS-NF-NEN-MIE | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
290295.100 Request information |  | MAXYMUM OXYGEN 100 bar | CGA | 9/16" | 300 | 100 | >200 | R | 1 | 1 | -- |
MAXYMUM 100 BAR - ARGON
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 100 BAR - ARGON
Available in four different calibrations, it is also ideal as a primary regulator for centralizations fed by cylinder packs up to 200 bar of pressure. They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
296200.100 Request information |  | MAXYMUM ARGON 100 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 100 | >200 | R | 1 | 1 | -- |
296201.100 Request information |  | MAXYMUM ARGON 100 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | R | 1 | 1 | -- |
296203.100 Request information |  | MAXYMUM ARGON 100 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | R | 1 | 1 | -- |
295202.100 Request information |  | MAXYMUM ARGON 100 BAR | NF | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | R | 1 | 1 | -- |
296209.100 Request information |  | MAXYMUM ARGON 100 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | R | 1 | 1 | -- |
296204.100 Request information |  | MAXYMUM ARGON 100 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | R | 1 | 1 | -- |
296202.100 Request information |  | MAXYMUM ARGON 100 BAR | MIE | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | R | 1 | 1 | -- |
296205.100 Request information |  | MAXYMUM ARGON 100 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 100 | >200 | R | 1 | 1 | -- |
MAXYMUM 100 BAR - HYDROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 100 BAR - HYDROGEN
Available in four different calibrations (20-40-60-100bar).
Ideal for applications where high gas flow rates are required such as feeding large cutting and/or heating torches or as a component for the construction of small decompression stations where a Hydrogen outlet pressure of up to 100bar is required.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
293200.100 Request information |  | MAXYMUM HYDROGEN 100BAR | UNI | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
293251.100 Request information |  | MAXYMUM HYDROGEN 100BAR | DIN | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
293203.100 Request information |  | MAXYMUM HYDROGEN 100BAR | BS | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
293201.100 Request information |  | MAXYMUM HYDROGEN 100BAR | NF-NEN-SS-MIE | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
293205.100 Request information |  | MAXYMUM HYDROGEN 100BAR | CGA | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
MAXYMUM 100 BAR - AIR
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 100 BAR - AIR
Available in four different calibrations (20-40-60-100bar)
Ideal for multiple applications in which compressed air is used such as inflating high-pressure lifting cushions.
They guarantee high flow rates up to 100bar of pressure.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
298250.100 Request information |  | MAXYMUM COMPRESSED AIR 100BAR | UNI | G1/4 | 200 | 100 | >200 | R | 1 | 1 | -- |
298253DIN.100 Request information |  | MAXYMUM COMPRESSED AIR 100BAR | DIN | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
298203.100 Request information |  | MAXYMUM COMPRESSED AIR 100BAR | BS-SS | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
298209.100 Request information |  | MAXYMUM COMPRESSED AIR 100BAR | NEN | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
298208.100 Request information |  | MAXYMUM COMPRESSED AIR 100BAR | MIE | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
298205.100 Request information |  | MAXYMUM COMPRESSED AIR 100BAR | CGA | G1/4 | 300 | 100 | >200 | R | 1 | 1 | -- |
MAXYMUM 60 BAR - NITROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 60 BAR - NITROGEN
Particularly suitable for cleaning air conditioning systems or inflating tires. Available with four different pressure settings.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE connections.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
294200 Request information |  | MAXYMUM NITROGEN 60 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 60 | <150 | D | 1 | 1 | |
294209 Request information |  | MAXYMUM NITROGEN 60 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294203 Request information |  | MAXYMUM NITROGEN 60 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294202 Request information |  | MAXYMUM NITROGEN 60 BAR | NF | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | |
2942049 Request information |  | MAXYMUM NITROGEN 60 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294204 Request information |  | MAXYMUM NITROGEN 60 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294205 Request information |  | MAXYMUM NITROGEN 60 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
MAXYMUM 60 BAR - OXYGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 60 BAR - OXYGEN
The lubrication of the internal O-rings of the regulator is carried out using a lubricant (specific grease) compatible with oxygen, approved by BAM. (Bundesanstalt fur Materialforschung)
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
290200 Request information |  | MAXYMUM OXYGEN 60 BAR | UNI-SS | G1/4 | 200 | 60 | <150 | D | 1 | 1 | -- |
290201 Request information |  | MAXYMUM OXYGEN 60 BAR | DIN | G1/4 | 300 | 60 | <150 | D | 1 | 1 | -- |
290203 Request information |  | MAXYMUM OXYGEN 60 BAR | BS-NF-NEN-MIE | G1/4 | 300 | 60 | <150 | D | 1 | 1 | -- |
290295 Request information |  | MAXYMUM OXYGEN 60 BAR | CGA | 9/16" | 300 | 60 | <150 | D | 1 | 1 | -- |
MAXYMUM 60 BAR - ARGON
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 60 BAR - ARGON
Available in four different calibrations, it is also ideal as a primary regulator for centralizations fed by cylinder packs up to 200 bar of pressure. They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
296200 Request information |  | MAXYMUM ARGON 60 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 60 | <150 | R | 1 | 1 | -- |
296201 Request information |  | MAXYMUM ARGON/CO2 60 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
295203 Request information |  | MAXYMUM ARGON 60 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296202 Request information |  | MAXYMUM ARGON 60 BAR | NF-MIE | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296209 Request information |  | MAXYMUM ARGON 60 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296204 Request information |  | MAXYMUM ARGON 60 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296205 Request information |  | MAXYMUM ARGON 60 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
MAXYMUM 60 BAR - CO2
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 60 BAR - CO2
Available in four different calibrations (20-40-60bar).
Ideal for application on cylinders/cylinder packs and for the creation of small decompression stations where a CO2 output pressure of up to 60 bar is required.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
295200 Request information |  | MAXYMUM CO2 60BAR | UNI-BS-NF-SS-MIE | 1/4 SAE + 5/16 SAE | 200 | 60 | <150 | R | 1 | 0 | -- |
296201 Request information | | MAXYMUM ARGON/CO2 60 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
295209 Request information |  | MAXYMUM CO2 60BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
295205 Request information |  | MAXYMUM CO2 60BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
MAXYMUM 60 BAR - HYDROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 60 BAR - HYDROGEN
Available in four different calibrations (20-40-60-100bar).
Ideal for applications where high gas flow rates are required such as feeding large cutting and/or heating torches or as a component for the construction of small decompression stations where a Hydrogen outlet pressure of up to 100bar is required.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
293200 Request information |  | MAXYMUM HYDROGEN 60BAR | UNI | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293251 Request information |  | MAXYMUM HYDROGEN 60BAR | DIN | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293203 Request information |  | MAXYMUM HYDROGEN 60BAR | BS | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293201 Request information |  | MAXYMUM HYDROGEN 60BAR | NF-NEN-SS-MIE | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293205 Request information |  | MAXYMUM HYDROGEN 60BAR | CGA | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
MAXYMUM 60 BAR - AIR
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 60 BAR - AIR
Available in four different calibrations (20-40-60-100bar)
Ideal for multiple applications in which compressed air is used such as inflating high-pressure lifting cushions.
They guarantee high flow rates up to 100bar of pressure.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
298250 Request information |  | MAXYMUM COMPRESSED AIR 60BAR | UNI | G1/4 | 200 | 60 | <150 | R | 1 | 1 | -- |
298253DIN Request information |  | MAXYMUM COMPRESSED AIR 60BAR | DIN | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298203 Request information |  | MAXYMUM COMPRESSED AIR 60BAR | BS-SS | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298209 Request information |  | MAXYMUM COMPRESSED AIR 60BAR | NEN | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298208 Request information |  | MAXYMUM COMPRESSED AIR 60BAR | MIE | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298205 Request information |  | MAXYMUM COMPRESSED AIR 60BAR | CGA | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
MAXYMUM 40 BAR - NITROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 40 BAR - NITROGEN
Particularly suitable for cleaning air conditioning systems or inflating tires. Available with four different pressure settings.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE connections.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
294200.40 Request information |  | MAXYMUM NITROGEN 40 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 40 | <100 | D | 1 | 1 | -- |
294209.40 Request information |  | MAXYMUM NITROGEN 40 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294203.40 Request information |  | MAXYMUM NITROGEN 40 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294202.40 Request information |  | MAXYMUM NITROGEN 40 BAR | NF | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
2942049.40 Request information |  | MAXYMUM NITROGEN 40 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294204.40 Request information |  | MAXYMUM NITROGEN 40 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
294205.40 Request information |  | MAXYMUM NITROGEN 40 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | D | 1 | 1 | -- |
MAXYMUM 40 BAR - OXYGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 40 BAR - OXYGEN
The lubrication of the internal O-rings of the regulator is carried out using a lubricant (specific grease) compatible with oxygen, approved by BAM.(Bundesanstalt fur Materialforschung)
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
290200.40 Request information |  | MAXYMUM OXYGEN 40 BAR | UNI-SS | G1/4 | 200 | 40 | <100 | R | 1 | 1 | -- |
290201.40 Request information |  | MAXYMUM OXYGEN 40 BAR | DIN | G1/4 | 300 | 60 | <150 | D | 1 | 1 | -- |
290203.40 Request information |  | MAXYMUM OXYGEN 40 BAR | BS-NF-NEN-MIE | G1/4 | 300 | 60 | <150 | D | 1 | 1 | -- |
290295.40 Request information |  | MAXYMUM OXYGEN 40 BAR | CGA | 9/16" | 300 | 60 | <150 | D | 1 | 1 | -- |
MAXYMUM 40 BAR - ARGON
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 40 BAR - ARGON
Available in four different calibrations, it is also ideal as a primary regulator for centralizations fed by cylinder packs up to 300 bar of pressure. They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
296200.40 Request information |  | MAXYMUM ARGON 40 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 40 | <100 | R | 1 | 1 | -- |
296201.40 Request information |  | MAXYMUM ARGON/CO2 40 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296203.40 Request information |  | MAXYMUM ARGON 40 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296202.40 Request information |  | MAXYMUM ARGON 40 BAR | NF-MIE | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296209.40 Request information |  | MAXYMUM ARGON 40 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296204.40 Request information |  | MAXYMUM ARGON 40 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
296205.40 Request information |  | MAXYMUM ARGON 40 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
MAXYMUM 40 BAR - CO2
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 40 BAR - CO2
Available in four different calibrations (20-40-60bar).
Ideal for application on cylinders/cylinder packs and for the creation of small decompression stations where a CO2 output pressure of up to 60 bar is required.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
295200.40 Request information |  | MAXYMUM CO2 40BAR | UNI-BS-NF-SS-MIE | 1/4 SAE + 5/16 SAE | 200 | 40 | <100 | R | 1 | 1 | -- |
296201.40 Request information | | MAXYMUM ARGON/CO2 40 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
295209.40 Request information |  | MAXYMUM CO2 40BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
295205.40 Request information |  | MAXYMUM CO2 40BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 60 | <150 | R | 1 | 1 | -- |
MAXYMUM 40 BAR - HYDROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 40 BAR - HYDROGEN
Available in four different calibrations (20-40-60-100bar).
Ideal for applications where high gas flow rates are required such as feeding large cutting and/or heating torches or as a component for the construction of small decompression stations where a Hydrogen outlet pressure of up to 100bar is required.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
293200.40 Request information |  | MAXYMUM HYDROGEN 40BAR | UNI | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293251.40 Request information |  | MAXYMUM HYDROGEN 40BAR | DIN | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293203.40 Request information |  | MAXYMUM HYDROGEN 40BAR | BS | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293201.40 Request information |  | MAXYMUM HYDROGEN 40BAR | NF-NEN-SS-MIE | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
293205.40 Request information |  | MAXYMUM HYDROGEN 40BAR | CGA | G1/4 | 300 | 60 | <150 | R | 1 | 1 | -- |
MAXYMUM 40 BAR - AIR
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 40 BAR - AIR
Available in four different calibrations (20-40-60-100bar)
Ideal for multiple applications in which compressed air is used such as inflating high-pressure lifting cushions.
They guarantee high flow rates up to 100bar of pressure.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
298250.40 Request information |  | MAXYMUM COMPRESSED AIR 40BAR | UNI | G1/4 | 200 | 40 | <150 | R | 1 | 1 | -- |
298253DIN.40 Request information |  | MAXYMUM COMPRESSED AIR 40BAR | DIN | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298203.40 Request information |  | MAXYMUM COMPRESSED AIR 40BAR | BS-SS | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298209.40 Request information |  | MAXYMUM COMPRESSED AIR 40BAR | NEN | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298208.40 Request information |  | MAXYMUM COMPRESSED AIR 40BAR | MIE | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
298205.40 Request information |  | MAXYMUM COMPRESSED AIR 40BAR | CGA | G1/4 | 300 | 60 | <150 | R | 2 | 1 | -- |
MAXYMUM 20 BAR - NITROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 20 BAR - NITROGEN
Particularly suitable for cleaning air conditioning systems or inflating tires. Available with four different pressure settings.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE connections.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
294200.20 Request information |  | MAXYMUM NITROGEN 20 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 20 | <60 | D | 1 | 1 | -- |
294209.20 Request information |  | MAXYMUM NITROGEN 20 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | D | 1 | 1 | -- |
294203.20 Request information |  | MAXYMUM NITROGEN 20 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | D | 1 | 1 | -- |
294202.20 Request information |  | MAXYMUM NITROGEN 20 BAR | NF | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | D | 1 | 1 | |
2942049.20 Request information |  | MAXYMUM NITROGEN 20 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | D | 1 | 1 | -- |
294204.20 Request information |  | MAXYMUM NITROGEN 20 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | D | 1 | 1 | -- |
294205.20 Request information |  | MAXYMUM NITROGEN 20 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | D | 1 | 1 | -- |
MAXYMUM 20 BAR - OXYGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 20 BAR - OXYGEN
The lubrication of the internal O-rings of the regulator is carried out using a lubricant (specific grease) compatible with oxygen, approved by BAM. ((Bundesanstalt fur Materialforschung)
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
290200.20 Request information |  | MAXYMUM OXYGEN 20 BAR | UNI-SS | G1/4 | 200 | 20 | <60 | R | 1 | 1 | -- |
290201.20 Request information |  | MAXYMUM OXYGEN 20 BAR | DIN | G1/4 | 300 | 20 | <150 | D | 1 | 1 | -- |
290203.20 Request information |  | MAXYMUM OXYGEN 20 BAR | BS-NF-NEN-MIE | G1/4 | 300 | 20 | <150 | D | 1 | 1 | -- |
290295.20 Request information |  | MAXYMUM OXYGEN 20 BAR | CGA | 9/16" | 300 | 20 | <150 | D | 1 | 1 | -- |
MAXYMUM 20 BAR - ARGON
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 20 BAR - ARGON
Available in four different calibrations, it is also ideal as a primary regulator for centralizations fed by cylinder packs up to 300 bar of pressure. They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
296200.20 Request information |  | MAXYMUM ARGON 20 BAR | UNI | 1/4 SAE + 5/16 SAE | 200 | 20 | <60 | R | 1 | 1 | -- |
296201.20 Request information |  | MAXYMUM ARGON/CO2 20 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
296203.20 Request information |  | MAXYMUM ARGON 20 BAR | BS | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
296202.20 Request information |  | MAXYMUM ARGON 20 BAR | NF-MIE | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
296209.20 Request information |  | MAXYMUM ARGON 20 BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
296204.20 Request information |  | MAXYMUM ARGON 20 BAR | SS | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
296205.20 Request information |  | MAXYMUM ARGON 20 BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
MAXYMUM 20 BAR - CO2
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 20 BAR - CO2
Available in four different calibrations (20-40-60bar).
Ideal for application on cylinders/cylinder packs and for the creation of small decompression stations where a CO2 output pressure of up to 60 bar is required.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
295200.20 Request information |  | MAXYMUM CO2 20BAR | UNI-BS-NF-SS-MIE | 1/4 SAE + 5/16 SAE | 200 | 20 | <60 | R | 1 | 1 | -- |
296201.20 Request information | | MAXYMUM ARGON/CO2 20 BAR | DIN | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
295209.20 Request information |  | MAXYMUM CO2 20BAR | NEN | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
295205.20 Request information |  | MAXYMUM CO2 20BAR | CGA | 1/4 SAE + 5/16 SAE | 300 | 20 | <150 | R | 1 | 1 | -- |
MAXYMUM 20 BAR - HYDROGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 20 BAR - HYDROGEN
Available in four different calibrations (20-40-60-100bar).
Ideal for applications where high gas flow rates are required such as feeding large cutting and/or heating torches or as a component for the construction of small decompression stations where a Hydrogen outlet pressure of up to 100bar is required.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
293200.20 Request information |  | MAXYMUM HYDROGEN 20BAR | UNI | G1/4 | 300 | 20 | <150 | R | 1 | 1 | -- |
293251.20 Request information |  | MAXYMUM HYDROGEN 20BAR | DIN | G1/4 | 300 | 20 | <150 | R | 1 | 1 | -- |
293203.20 Request information |  | MAXYMUM HYDROGEN 20BAR | BS | G1/4 | 300 | 20 | <150 | R | 1 | 1 | -- |
293201.20 Request information |  | MAXYMUM HYDROGEN 20BAR | NF-NEN-SS-MIE | G1/4 | 300 | 20 | <150 | R | 1 | 1 | -- |
293205.20 Request information |  | MAXYMUM HYDROGEN 20BAR | CGA | G1/4 | 300 | 20 | <150 | R | 1 | 1 | -- |
MAXYMUM 20 BAR - AIR
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXYMUM - MAXYMUM 20 BAR - AIR
Available in four different calibrations (20-40-60-100bar)
Ideal for multiple applications in which compressed air is used such as inflating high-pressure lifting cushions.
They guarantee high flow rates up to 100bar of pressure.
They are supplied with a kit of two 1/4 SAE and 5/16 SAE fittings.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
298250.20 Request information |  | MAXYMUM COMPRESSED AIR 20BAR | UNI | G1/4 | 200 | 20 | <150 | R | 1 | 1 | -- |
298253DIN.20 Request information |  | MAXYMUM COMPRESSED AIR 20BAR | DIN | G1/4 | 300 | 20 | <150 | R | 2 | 1 | -- |
298203.20 Request information |  | MAXYMUM COMPRESSED AIR 20BAR | BS-SS | G1/4 | 300 | 20 | <150 | R | 2 | 1 | -- |
298209.20 Request information |  | MAXYMUM COMPRESSED AIR 20BAR | NEN | G1/4 | 300 | 20 | <150 | R | 2 | 1 | -- |
298208.20 Request information |  | MAXYMUM COMPRESSED AIR 20BAR | MIE | G1/4 | 300 | 20 | <150 | R | 2 | 1 | -- |
298205.20 Request information |  | MAXYMUM COMPRESSED AIR 20BAR | CGA | G1/4 | 300 | 20 | <150 | R | 2 | 1 | -- |
Frequently asked questions
How can I return a product or get a refund?
You can request a return for a product ordered by mistake within 5 days of delivery. The refund will be 80% of the product value, subject to verification of its condition and quality.
What are the delivery times?
Products marked D (available) are normally shipped within 48/72 hours. Products in class R (on request) are shipped according to the date stated in the order confirmation.
What warranties apply to the products?
Our warranty covers any manufacturing defect and provides:
- 36 months from delivery for all pressure regulators
- 24 months from delivery for all other products
- 12 months from delivery for all electric welding products
The data and images contained in this catalog are purely indicative and may be subject to change without prior notice from Oxyturbo SpA. Photographs and product descriptions are not contractually binding and may only be used with the prior authorization of Oxyturbo SpA.
