PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS
MAXY POWER CONTROL
MAXY POWER CONTROL
Pressure regulators with 2 pressure gauges for all industrial uses, even intensive ones, with outlet shut-off valve and connections for Oxygen, Acetylene, Argon/CO2 gases.
Characteristics
Entirely designed and manufactured in Italy for over 20 years, the MAXY regulator has always been appreciated for its robustness, reliability, and excellent delivery stability once the pressure or flow parameter has been set, until the gas cylinder is exhausted.
The body is made of carefully pickled brass with an automated system that guarantees the absence of oxidation over time without the need for additional paint, thus making it possible to immediately recycle the brass at the end of the product's life, fully respecting the environment.
Use
The CO2 or Argon Mix versions are ideal for equipping MIG/MAG/TIG welding units with outputs of up to 32 liters per minute, a value more than sufficient to cover all applications.
The Oxygen/Acetylene versions guarantee sufficient output flow for all cutting operations on steel up to 30 cm thickness!(12 inches)
EASE OF USE
The PowerControl version is also equipped with an outlet shut-off valve that allows you to shut off the gas flow at the end of operations without having to adjust the main control knob, thus maintaining the set value for quicker resumption of work.
STABLE DISTRIBUTION
MAXY regulators are designed to achieve excellent output stability from full to empty cylinders without having to significantly readjust parameters during operation.
OUR CERTIFICATIONS, YOUR SAFETY
All our regulators comply with the international standard EN-ISO2503, and the versions for combustion and combustible gases (oxygen/acetylene) are also certified by APRAGAZ, a Belgian inspection and certification body specialised in pressure equipment.Certificates
Product Sectors
MAXY POWER CONTROL FOR MIG/MAG/TIG WELDING - ARGON
MAXY POWER CONTROL FOR OXYGEN/ACETYLENE - OXYGEN
MAXY POWER CONTROL FOR MIG/MAG/TIG WELDING - CO2
MAXY POWER CONTROL FOR OXYGEN/ACETYLENE WELDING - MAXY POWER CONTROL FOR ACETYLENE
MAXY POWER CONTROL FOR MIG/MAG/TIG WELDING - ARGON
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXY POWER CONTROL - MAXY POWER CONTROL FOR MIG/MAG/TIG WELDING - ARGON
The outlet valve intercepts the gas and allows the flow to be opened and closed without having to use the main control knob, which thus remains calibrated for subsequent use. However, it is recommended to always close the valve on the gas cylinder after use.
For improved performance, we have included Ø 63 mm pressure gauges up to 32 l/min at 4 bar.
The pressure gauges are one of the most delicate parts of the regulator, containing the gas at maximum pressure (200 bar/2900PSI) with internal micro-welding to ensure leak-proofing. For this reason, Oxyturbo uses only WIKA pressure gauges, a German company, a world leader in pressure gauge manufacturing..
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
266500 Request information | | MAXY PC ARGON/MIX W/CAP | UNI-CGA | G1/4 | 200 | 4 | >2 | D | 1 | 1 | -- |
266501 Request information |  | MAXY PC CO2/ARGON W/CAP | DIN | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
266503 Request information |  | MAXY PC ARGON W/CAP | BS | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
265500 Request information |  | MAXY PC CO2 W/CAP | UNI-BS-NF-SS-MIE | G1/4 | 200 | 4 | >2 | D | 1 | 1 | -- |
266509 Request information |  | MAXY PC ARGON W/CAP | NEN | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
266504 Request information |  | MAXY PC ARGON W/CAP | SS | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
266550 Request information |  | MAXY PC ARGON W/CAP | UNI-CGA | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
266551 Request information |  | MAXY PC ARGON W/CAP | DIN | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
266553 Request information |  | MAXY PC ARGON W/CAP | BS | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
265550 Request information |  | MAXY PC CO2/ARGON W/CAP | UNI-BS-NF-SS-MIE | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
266559 Request information |  | MAXY PC ARGON W/CAP | NEN | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
266554 Request information |  | MAXY PC ARGON W/CAP | SS | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
MAXY POWER CONTROL FOR OXYGEN/ACETYLENE - OXYGEN
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXY POWER CONTROL - MAXY POWER CONTROL FOR OXYGEN/ACETYLENE - OXYGEN
The presence of the control tap in the Power Control version helps to improve the stabiliser as well as Maxy pressure regulator function.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
260500 Request information |  | MAXY PC OXYGEN | UNI-SS | G1/4 | 300 | 10 | 30 | D | 1 | 1 | -- |
260501 Request information |  | MAXY PC OXYGEN | DIN | G1/4 | 300 | 10 | 30 | D | 1 | 1 | -- |
260503 Request information |  | MAXY PC OXYGEN | BS-NF-NEN-MIE | G1/4 | 300 | 10 | 30 | D | 1 | 1 | -- |
260550 Request information |  | MAXY PC OXYGEN | UNI-SS | G3/8 | 200 | 10 | 30 | D | 1 | 1 | |
260551 Request information |  | MAXY PC OXYGEN | DIN | G3/8 | 300 | 10 | 30 | D | 1 | 1 | -- |
260553 Request information |  | MAXY PC OXYGEN | BS-NF-NEN-MIE | G3/8 | 300 | 10 | 30 | D | 1 | 1 | -- |
260593 Request information |  | MAXY PC OXYGEN | NF | 9/16" | 300 | 10 | 30 | D | 1 | 1 | -- |
260595 Request information |  | MAXY PC OXYGEN | CGA | 9/16" | 300 | 10 | 30 | D | 1 | 1 | -- |
260583 Request information |  | MAXY PC OXYGEN | NF | M16X1.5 | 300 | 10 | 30 | D | 1 | 1 | -- |
260585 Request information |  | MAXY PC OXYGEN | CGA | M16X1.5 | 300 | 10 | 30 | D | 1 | 1 | -- |
MAXY POWER CONTROL FOR MIG/MAG/TIG WELDING - CO2
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXY POWER CONTROL - MAXY POWER CONTROL FOR MIG/MAG/TIG WELDING - CO2
The outlet valve intercepts the gas and allows the flow to be opened and closed without having to use the main control knob, which thus remains calibrated for subsequent use. However, it is recommended to always close the valve on the gas cylinder after use.
For improved performance, we have included Ø 63 mm pressure gauges up to 32 l/min at 4 bar.
The pressure gauges are one of the most delicate parts of the regulator, containing the gas at maximum pressure (200 bar) with internal micro-welding to ensure leak-proofing. For this reason, Oxyturbo uses only WIKA pressure gauges, a German company, a world leader in pressure gauge manufacturing.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
265500 Request information | | MAXY PC CO2 W/CAP | UNI-BS-NF-SS-MIE | G1/4 | 200 | 4 | >2 | D | 1 | 1 | -- |
266501 Request information | | MAXY PC CO2/ARGON W/CAP | DIN | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
265509 Request information |  | MAXY PC CO2 W/CAP | NEN | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
265505 Request information |  | MAXY PC CO2 W/CAP | CGA | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
265550 Request information | | MAXY PC CO2/ARGON W/CAP | UNI-BS-NF-SS-MIE | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
266551 Request information | | MAXY PC ARGON W/CAP | DIN | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
265559 Request information |  | MAXY PC CO2 W/CAP | NEN | G1/4 | 300 | 4 | >2 | D | 1 | 1 | -- |
265555 Request information |  | MAXY PC CO2 W/CAP | CGA | G3/8 | 300 | 4 | >2 | D | 1 | 1 | -- |
MAXY POWER CONTROL FOR OXYGEN/ACETYLENE WELDING - MAXY POWER CONTROL FOR ACETYLENE
PRESSURE REGULATORS FOR RECHARGEABLE CYLINDERS - MAXY POWER CONTROL - MAXY POWER CONTROL FOR OXYGEN/ACETYLENE WELDING - MAXY POWER CONTROL FOR ACETYLENE
The presence of the control tap in the Power Control version helps to improve the stabiliser as well as Maxy pressure regulator function.
| Code | Image | Description | Normative | Outlet | P1 (bar) | P2 (bar) | Q1 (m³/h) | Availability | Weight (kg) | No. of pcs | Product sheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
261503 Request information |  | MAXY PC ACETYL. W/Bullnose G1/4 Lh | UNI-BS-NF-NEN-MIE | G1/4 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261504 Request information |  | MAXY PC ACETYL. W/Bullnose G1/4 Lh | SS | G1/4 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261553 Request information |  | MAXY PC ACETYL. W/Bullnose | UNI-BS-NF-NEN-MIE | G3/8 | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261554 Request information |  | MAXY PC ACETYL. W/Bullnose G1/4 Lh | SS | G3/8 | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261500 Request information |  | MAXY PC ACETYL. W/Yoke G1/4 Lh | UNI-NF | G1/4 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261501 Request information |  | MAXY PC ACETYL. W/Yoke G1/4 Lh | DIN | G1/4 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261509 Request information |  | MAXY PC ACETYL. W/Yoke G1/4 Lh | NEN | G1/4 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261550 Request information |  | MAXY PC ACETYL. W/Yoke | UNI-NF | G3/8 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261551 Request information |  | MAXY PC ACETYL. W/Yoke G1/4 Lh | DIN | G3/8 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261559 Request information |  | MAXY PC ACETYL. W/Yoke | NEN | G3/8 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261595 Request information |  | MAXY PC ACETYL. W/Bullnose 9/16" Lh | CGA | 9/16" | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261583 Request information |  | MAXY PC ACETYL. W/Bullnose M16X1.5 Lh | NF | M16X1.5 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
261580 Request information |  | MAXY PC ACETYL. W/Yoke M16X1.5 Lh | NF | M16X1.5 LH | 25 | <1,5 | 5 | D | 1 | 1 | -- |
Technical questions and evidence
How can I compare the available variants?
Use the comparison table above: codes and technical properties come directly from the Oxyturbo product database.
Which supporting documents are available?
The technical sheets, manuals and certificates shown on this page are the documents currently associated with this product family.
How do I verify compatibility with my application?
Check gas, pressure, connection and flow data for the exact code, then send that code with the application requirements to Oxyturbo for confirmation.
The data and images contained in this catalog are purely indicative and may be subject to change without prior notice from Oxyturbo SpA. Photographs and product descriptions are not contractually binding and may only be used with the prior authorization of Oxyturbo SpA.
